Portalp RS

The new PORTALP RS shows its innovative character. Its new compact design and drive unit with new technology allow you to choose your door in sliding and telescopic versions.

Choose its installation and opening configurations (single sliding, double sliding, telescopic, panic), operating programs, colors, finishes and accessories.

With our new AUTODOOR PILOT app control your new Portalp RS automatic door! You have four control functions: six-mode selector switch, key switch, priority opening and automatic opening.

The AUTODOOR MASTER application, meanwhile, is dedicated to authorized professionals for all configurations, settings and startups.

Product benefits

  • Compact mechanism
  • Low power switching power supply
  • Efficient and silent brushless motor
  • Smartphone-based control
  • Secure Bluetooth Low Energy (BLE) connection
  • Emergency exit compatible (EN16005)

AVAILABLE IN THE FOLLOWING AREAS

Africa, Asia, North America, Latin America, Europe, Middle East

MECHANICAL SPECIFICATIONS

A sober and refined line

  • Aluminium header H 120 mm
  • Neat finish, sturdy flanges
  • Adjusted closing of the cover

Flexibility of installation to meet various environmental constraints

  • Surface, wall-to-wall or spine installation
  • Narrow to wide passages 750 à 3400 mm
  • Standard passage height up to 3100 mm

Different types of panels according to the desired thermal/acoustic performances

  • Frame G25, G38, G50 RPT, API (antipanic)
  • Single or double glazing up to 26 mm
  • Fast glass replacement in case of glass breakage
  • Frameless Lumina all-glass panels(interior doors)
  • Door panel weight up to 1 x 250 kg (single) or 2 x 200 kg (double)

OPÉRATOR SPECIFICATIONS

  • A flexible and innovative management system
  • Connection of many peripherals
  • Possibility of adding logic input/output cards
  • Adjustment of the kinetics of the panels for a fluid and secure movement

CONNECTIVITY

  • Secure connection with digital keys
  • Android/Apple application
  • Intuitive graphical interface

OPTIONS

  • Wide choice of RAL colors (consult us)
  • Possibility of intermediate rails on fixed / sliding panels
  • Other control devices: LCD display, IR remote control, key switch, contactless switch, etc.
  • Management of doors in SAS mode to limit heat loss and regulate flows
  • Electric or manual locking systems
  • Manual release systems
  • Opening device with Intrinsic Mechanical Energy (EMI) according to CO48
  • Burglar-proof motorized lock
  • Floor guide rail
  • Nouveau : commande extérieure sécurisée
  • PAC – Access control unit
×
